The following limit is for our generan type paper bowl machine(LBZ-LC single side PE coated paper bowl machine and LBZ-LD double sides PE coated paper bowl machine)

• A == Paper bowl bottom diameter (outside) , Min 75mm---Max 150mm
• B == Paper bowl top diameter (inside) , Min 60mm---Max 120mm
• C == Paper bowl height , Min 40mm ---Max 128mm
• D == The coning of paper bowls, Min 2.6Degree ---- Max 12 Degreee
• E == the paper bowl side sealing width , Min 6mm --- Max 14 mm, the general is 10mm
• F == Bowl bottom height, Min 6mm --- Max 15 mm, the general type is 10mm
• G == the top curling diameter, from 3mm to 8mm, this is decided by the paper weight(the paper thickness),
• I == Paper bowl bottom diameter( inside), it is a little difficult for you to measure,
• Please note: the range given is just for our general type paper bowl machines( for LBZ-LIII and LBZ-LIII paper bowl machines), if you want is a special one, don't hesitate to let us know, for we can do it according to your requirement.

When you decide to place an order, please send us your samples or let us know the following paper bowls sizes :

• A= bottom diameter(outside), B=top diameter (outside or inside), C=height,
• The above three sizes are demanded .
• The other sizes, E=side sealing width, F=bottom knurling height, G=top curling diameter, The more details providing is appreciated.
• If you don't offer the sizes E,F,G . We will choose the General Size for you.
